Source catalogue data
| Diameter | Weight | Breaking load | Diameter | Weight | Breaking load |
|---|---|---|---|---|---|
| 2.5 mm | 0.57 kg/100m | 200 kgf | 3/32" | 0.38 lbs/100ft | 441 lbs |
| 2.8 mm | 0.66 kg/100m | 245 kgf | 7/64" | 0.44 lbs/100ft | 540 lbs |
| 3 mm | 0.8 kg/100m | 320 kgf | 1/8" | 0.54 lbs/100ft | 705 lbs |
| 3.5 mm | 1 kg/100m | 360 kgf | 9/64" | 0.67 lbs/100ft | 794 lbs |
| 4 mm | 1.3 kg/100m | 440 kgf | 5/32" | 0.87 lbs/100ft | 970 lbs |
| 4.5 mm | 1.83 kg/100m | 540 kgf | 11/64" | 1.23 lbs/100ft | 1191 lbs |
| 5 mm | 2 kg/100m | 680 kgf | 3/16" | 1.34 lbs/100ft | 1499 lbs |
| 5.5 mm | 2.48 kg/100m | 770 kgf | 7/32" | 1.67 lbs/100ft | 1698 lbs |
| 6 mm | 2.68 kg/100m | 840 kgf | 1/4" | 1.8 lbs/100ft | 1852 lbs |
| 8 mm | 5.1 kg/100m | 1250 kgf | 5/16" | 3.43 lbs/100ft | 2756 lbs |
| 10 mm | 8 kg/100m | 1970 kgf | 3/8" | 5.38 lbs/100ft | 4343 lbs |
| 12 mm | 11.5 kg/100m | 2950 kgf | 1/2" | 7.73 lbs/100ft | 6504 lbs |
| 14 mm | 15 kg/100m | 4100 kgf | 9/16" | 10.08 lbs/100ft | 9039 lbs |
| 16 mm | 20 kg/100m | 5250 kgf | 5/8" | 13.44 lbs/100ft | 11574 lbs |
| 18 mm | 24.6 kg/100m | 6800 kgf | 3/4" | 16.53 lbs/100ft | 14991 lbs |
| 20 mm | 31.6 kg/100m | 8000 kgf | 13/16" | 21.23 lbs/100ft | 17637 lbs |
| 22 mm | 40 kg/100m | 9700 kgf | 7/8" | 26.88 lbs/100ft | 21385 lbs |
| 24 mm | 46 kg/100m | 11400 kgf | 1" | 30.91 lbs/100ft | 25133 lbs |
| 26 mm | 53 kg/100m | 13700 kgf | 1-1/16" | 35.61 lbs/100ft | 30203 lbs |
| 28 mm | 60 kg/100m | 16100 kgf | 1-1/8" | 40.32 lbs/100ft | 35494 lbs |
| 30 mm | 70 kg/100m | 18000 kgf | 1-1/4" | 47.04 lbs/100ft | 39683 lbs |
| 32 mm | 80 kg/100m | 20000 kgf | 1-5/16" | 53.76 lbs/100ft | 44092 lbs |
Unspliced · ISO 2307
