Technical rope data

LUPA® FAST-DKT

Catalogue product. Technical values below are taken from the source catalogue data used by ROPE FINDER.

Source catalogue data

Technical rope data

Diameter32–44 mm
Weight55–98 kg/100m
Breaking load7500–13340 kgf
Material
100% Polyamide BCF Fiber
Construction
8 Strand Plaited
Source catalogues
Fast Ropes
Related markets
—
LUPA® FAST-DKT catalogue product image

Applications

Applications

Personnel Insertion and Extraction

Benefits

Benefits

Good Breaking LoadMinimal SlippageSoft TouchDurableEasy To SpliceDoes Not Kink

Source catalogue data

Technical rope data

Fast Ropes 2024 · PDF 14

Type
L
Specific Gravity
1,14 kg/dm³
UV Resistance
Very Good
Chemical Resistance
Good
Melting Point
218°C
Critical Temperature
130°C
Elongation at Break
Max. %59
Fiber Water Absorption
Approx. %3-4
Wet Abrasion
Sufficient
Dry Abrasion
Good
Length
50-60-90-120 ft
Availability Note
Other Colours on Request
Termination Type
DKT
Termination Minimum Strength kgf
6000
Termination Minimum Strength lbs
13250
Metric Lengths
15,2-18,3-27,4-36,6 meters
Length Tolerance
-0%, +10%
Material
100% Polyamide BCF Fiber
Construction
8 Strand Plaited
Design Details
11 mm (7/16") Dyne K® Termination (DKT) Whip End

Technical variants

Catalogue variant data

Compare the catalogue ranges first, then review the exact variants below.

DiameterWeightBreaking load – UnsplicedBreaking load – Spliced
32 mm55 kg/100m8340 kgf7500 kgf
40 mm76 kg/100m11120 kgf10000 kgf
44 mm98 kg/100m13340 kgf12000 kgf

Technical values below are taken from the source catalogue data used by ROPE FINDER.
