Technical rope data
Catalogue product. Technical values below are taken from the source catalogue data used by ROPE FINDER.
Source catalogue data
Applications
Benefits
Source catalogue data
Technical variants
Compare the catalogue ranges first, then review the exact variants below.
| Diameter | Weight | Breaking load | Breaking load – Spliced |
|---|---|---|---|
| 4 mm | 0.98 kg/100m | 380 kgf | — |
| 5 mm | 1.54 kg/100m | 570 kgf | — |
| 6 mm | 2.22 kg/100m | 810 kgf | — |
| 8 mm | 3.95 kg/100m | 1420 kgf | — |
| 10 mm | 6.17 kg/100m | 2160 kgf | — |
| 12 mm | 8.88 kg/100m | 3060 kgf | — |
| 14 mm | 12.1 kg/100m | 4250 kgf | — |
| 16 mm | 15.8 kg/100m | 5280 kgf | — |
| 18 mm | 20 kg/100m | 6875 kgf | — |
| 20 mm | 24.7 kg/100m | 8500 kgf | — |
| 22 mm | 29.9 kg/100m | 10250 kgf | — |
| 24 mm | 35.5 kg/100m | 12000 kgf | — |
| 26 mm | 41.7 kg/100m | 14500 kgf | — |
| 28 mm | 48.4 kg/100m | 17000 kgf | — |
| 30 mm | 55.5 kg/100m | 19000 kgf | — |
| 32 mm | 63.2 kg/100m | 21125 kgf | — |
| 36 mm | 80 kg/100m | 27500 kgf | — |
| 40 mm | 98.7 kg/100m | 34000 kgf | — |
| 48 mm | 142 kg/100m | 48000 kgf | — |
| 56 mm | 193 kg/100m | 68000 kgf | — |
| 64 mm | 253 kg/100m | 84500 kgf | — |
Technical values below are taken from the source catalogue data used by ROPE FINDER.
