Technical rope data
Catalogue product. Technical values below are taken from the source catalogue data used by ROPE FINDER.
Source catalogue data
Applications
Benefits
Source catalogue data
Technical variants
Compare the catalogue ranges first, then review the exact variants below.
| Diameter | Weight | Breaking load | Breaking load – Spliced |
|---|---|---|---|
| 4 mm | 1.21 kg/100m | 325 kgf | — |
| 5 mm | 1.9 kg/100m | 515 kgf | — |
| 6 mm | 2.73 kg/100m | 720 kgf | — |
| 8 mm | 4.85 kg/100m | 1300 kgf | — |
| 10 mm | 7.58 kg/100m | 2060 kgf | — |
| 12 mm | 10.9 kg/100m | 2875 kgf | — |
| 14 mm | 14.9 kg/100m | 3875 kgf | — |
| 16 mm | 19.4 kg/100m | 5000 kgf | — |
| 18 mm | 24.6 kg/100m | 6250 kgf | — |
| 20 mm | 30.3 kg/100m | 8250 kgf | — |
| 22 mm | 36.7 kg/100m | 10000 kgf | — |
| 24 mm | 43.7 kg/100m | 11500 kgf | — |
| 26 mm | 51.2 kg/100m | 13500 kgf | — |
| 28 mm | 59.4 kg/100m | 15500 kgf | — |
| 30 mm | 68.2 kg/100m | 17750 kgf | — |
| 32 mm | 77.6 kg/100m | 20000 kgf | — |
| 36 mm | 98.4 kg/100m | 25000 kgf | — |
| 40 mm | 121 kg/100m | 33000 kgf | — |
| 48 mm | 175 kg/100m | 46000 kgf | — |
| 56 mm | 238 kg/100m | 62000 kgf | — |
| 64 mm | 311 kg/100m | 80000 kgf | — |
Technical values below are taken from the source catalogue data used by ROPE FINDER.
