Technical rope data
Catalogue product. Technical values below are taken from the source catalogue data used by ROPE FINDER.
Source catalogue data
Applications
Benefits
Source catalogue data
Technical variants
Compare the catalogue ranges first, then review the exact variants below.
| Diameter | Weight | Breaking load | Breaking load – Spliced |
|---|---|---|---|
| 4 mm | 0.72 kg/100m | 320 kgf | — |
| 5 mm | 1.13 kg/100m | 480 kgf | — |
| 6 mm | 1.63 kg/100m | 680 kgf | — |
| 8 mm | 2.89 kg/100m | 1200 kgf | — |
| 10 mm | 4.52 kg/100m | 1730 kgf | — |
| 12 mm | 6.51 kg/100m | 2550 kgf | — |
| 14 mm | 8.86 kg/100m | 3410 kgf | — |
| 16 mm | 11.6 kg/100m | 4330 kgf | — |
| 18 mm | 14.6 kg/100m | 5400 kgf | — |
| 20 mm | 18.1 kg/100m | 6500 kgf | — |
| 22 mm | 21.9 kg/100m | 7740 kgf | — |
| 24 mm | 26 kg/100m | 9180 kgf | — |
| 26 mm | 30.6 kg/100m | 10810 kgf | — |
| 28 mm | 35.4 kg/100m | 12900 kgf | — |
| 30 mm | 40.7 kg/100m | 14600 kgf | — |
| 32 mm | 46.3 kg/100m | 16400 kgf | — |
| 36 mm | 58.6 kg/100m | 20100 kgf | — |
| 40 mm | 72.3 kg/100m | 24300 kgf | — |
| 48 mm | 104 kg/100m | 34170 kgf | — |
| 56 mm | 142 kg/100m | 44600 kgf | — |
| 64 mm | 185 kg/100m | 57120 kgf | — |
Technical values below are taken from the source catalogue data used by ROPE FINDER.
