Technical rope data
Catalogue product. Technical values below are taken from the source catalogue data used by ROPE FINDER.
Source catalogue data
Applications
Benefits
Source catalogue data
Technical variants
Compare the catalogue ranges first, then review the exact variants below.
| Shackle diameter (mm) | Rope diameter (mm) | Length in closed condition (cm) | Shackle-1 weight (kg) | Shackle-1 minimum breaking load (kgf) | Shackle-2 weight (kg) | Shackle-2 minimum breaking load (kgf) | Shackle-3 weight (kg) | Shackle-3 minimum breaking load (kgf) |
|---|---|---|---|---|---|---|---|---|
| 12 | 7 | 12,5 | 0,03 | 4.670 | 0,05 | 10.508 | 0,07 | 15.785 |
| 14 | 8 | 15,0 | 0,05 | 5.980 | 0,07 | 13.455 | 0,11 | 20.212 |
| 18 | 10 | 17,5 | 0,09 | 9.380 | 0,13 | 21.105 | 0,20 | 31.704 |
| 20 | 12 | 20,0 | 0,14 | 13.460 | 0,21 | 30.285 | 0,32 | 45.495 |
| 24 | 14 | 35,0 | 0,33 | 18.360 | 0,49 | 41.310 | 0,75 | 62.057 |
| 28 | 16 | 40,0 | 0,48 | 23.700 | 0,72 | 53.325 | 1,11 | 80.106 |
Spliced Break Load (All tests are in Accordance with ISO 2307)
Technical values below are taken from the source catalogue data used by ROPE FINDER.
